S.E. Civil 2019 Pattern- Mechanics of Structures Practical's

5. Impact Test on metals- Charpy Test

        The Charpy impact test, also known as the Charpy V-notch test, is a high strain-rate test that involves striking a standard notched specimen with a controlled weight pendulum swung from a set height. The impact test helps measure the amount of energy absorbed by the specimen during fracture.

Please watch video for more details
